Ride and Handling Optimization Switch (86.65.11)

Removal

NOTE:











Automatic transmission shown. Manual transmission is similar.

1 .



   WARNING: The gear lever knob will be released suddenly, keep face clear during removal.

  Remove the selector lever knob.



Pull the knob upwards.



2 .

  Release the ride and handling optimization switch assembly.



Release the 4 clips.



3 .

  Release the selector lever panel.



Release the 4 clips.



4 .

  Remove the ride and handling optimization switch assembly.
