Tires Front Antenna(86.53.16)

Tire Pressure Monitoring System Front Antenna (86.53.16)

Removal

Installation

1 .

   WARNING: Do not work on or under a vehicle supported only by a jack. Always support the

vehicle on safety stands.

  Raise and support the vehicle.

2 .

Remove the fender splash shield. For additional information, refer to

Fender Splash Shield

(76.10.48)

 (Section 501-02)

3 .

  Remove the tire pressure antenna.

Remove the 2 retainers.

1 .

  To install, reverse the removal procedure.

2 .

  Initiate a new tire pressure antenna using T4.
