Land Rover LR3/Disco 308 · 204-02 Rear Suspension
08 · Steering & suspension

Wheel Bearing & Hub(64.15.14) (page 4 of 6)

Make
Land Rover
Model
Discovery LR3/Disco 3
204-02 Rear SuspensionWheel Bearing & Hub(64.15.14) · page 4 of 6
background image





Installation





10 .

  Remove the brake disc dust shield.



Remove the 3 screws.



11 .

  Using the special tools, remove the wheel bearing.



Remove the circlip.



1 .

  Clean the components.

2 .

  Using the special tools, install the wheel bearing.



3 .



   CAUTION: Make sure that the bearing seal is not damaged when installing the circlip.

Install the circlip.
