Upper Arm(64.35.60)

Upper Arm (64.35.60)

Removal

1 .

   WARNING: Do not work on or under a vehicle supported only by a jack. Always support the

vehicle on safety stands.

  Raise and support the vehicle.

2 .

  Remove the wheel and tire.

3 .

   CAUTION: Always plug any open connections to prevent contamination.

Remove the brake tube.

Disconnect the 2 brake tube unions.

Remove the brake hose clips and release the hoses.

Release the brake tube from the clip.

4 .

  Disconnect the height sensor link arm.

5 .

  Release the wheel speed sensor lead.

6 .

  RH side only: Release the brake pad wear indicator sensor lead.

7 .

  Remove the upper arm.

Loosen the upper arm bolts.
