Stabilizer Link (64.35.24)

Stabilizer Bar Link (64.35.24)

Removal

Installation

1 .

   WARNING: Do not work on or under a vehicle supported only by a jack. Always support the

vehicle on safety stands.

  Raise and support the vehicle.

2 .

  Remove the wheel and tire.

3 .

   CAUTION: Use a wrench on the hexagon provided to prevent the ball joint rotating.

Remove the stabilizer bar link.

1 .

  Install the stabilizer bar link.

Tighten the nuts to 115 Nm (85 lb.ft).

2 .

  Install the wheel and tire.

Tighten the wheel nuts to 140 Nm (103 lb.ft).
