Stabilizer Bar(64.35.08)

Stabilizer Bar (64.35.08)

Removal

   CAUTION: It is possible to install the stabilizer bar incorrectly. Note the position of the stabilizer bar

before removal.

1 .

   WARNING: Do not work on or under a vehicle supported only by a jack. Always support the

vehicle on safety stands.

  Raise and support the vehicle.

2 .

Remove the rear bumper cover. For additional information, refer to

Rear Bumper Cover (76.22.74)

(Section 501 -19)

3 .

  Remove the spare wheel and tire.

4 .

  Raise the vehicle.

5 .

  Remove the rear wheels and tires.

6 .

   CAUTION: Use a wrench on the hexagon provided to prevent the ball joint rotating.

Release both stabilizer bar links.

Remove the 2 nuts.

7 .

  Remove the body mount retaining bolts.

Remove the 8 bolts.
