Stabilizer Bar (60.10.01) (page 2 of 2)

Installation

7 .

  Remove the stabilizer bar.

Remove the stabilizer bar out through the LH side wheel arch.

1 .

  Install the stabilizer bar.

Install the stabilizer bar through the LH side wheel arch.

2 .

  Install the stabilizer bar bushing.

Install the stabilizer bar clamps.

Tighten the nuts to 115 Nm (85 lb.ft).

3 .

  Install the front axle crossmember.

Tighten the 4 bolts to 115 Nm (85 lb.ft).

4 .

Install the engine undershield. For additional information, refer to

Engine Undershield (76.10.50)

(Section 501 -02)

5 .

  Connect both stabilizer bar links to the stabilizer bar.

Tighten the nuts to 115 Nm (85 lb.ft).

6 .

  Install the wheels and tires.

Tighten the wheel nuts to 140 Nm (103 lb.ft).
