Front Seats

SEATS

76-5-2

DESCRIPTION AND OPERATION

Description

Front Seats
There are three versions of seat available for the New Range Rover. The front seats are fitted with the seat belt bolted
to the seat rail. The seat buckle, bolted to the seat frame, is supplied, for the US market, with a seat belt warning
switch.

The three seat options available are:

l

Manual seat – finished in cloth

l

Electric seat – finished in cloth

l

Contour seat – finished in Oxford Leather.

The electric and contour seats are fitted with a folding armrest (manually adjustable) on the inboard side of the seat,
additional optional equipment is: seat heating and memory recall facility.

Manual Seats

Manual Seat — Adjustment

1 Seat back adjustment
2 Height adjustment
3 Lumbar support adjustment

4 Forward/backward adjustment
5 Cushion front edge adjustment (driver's seat

only)

The manual seats are adjustable in the following axes:

l

Forward/backward

l

Seat height

l

Seat angle — driver's seat only

l

Backrest angle

l

Headrest height and angle.

Electrically adjusted lumbar support, in the  horizontal and vertical axes is available as optional equipment.

M76 4562

!

"

#
