SRS Control Diagram (page 2 of 2)
- Make
- Land Rover
- Model
- Range Rover L322 Range Rover System Description and Operation
RESTRAINT SYSTEMSSRS Control Diagram · page 2 of 2
RESTRAINT SYSTEMS
DESCRIPTION AND OPERATION
75-19
1 Ignition switch
2 Occupancy detection sensor
3 Driver airbag
4 Rotary coupler
5 Passenger airbag
6 Battery disconnection unit
7 BCU
8 Instrument pack
9 Diagnostic socket
10 RH side airbag
11 LH side airbag
12 RH front head airbag
13 RH rear head airbag
14 LH front head airbag
15 LH rear head airbag
16 DCU
17 RH side impact sensor
18 LH side impact sensor
19 Driver pretensioner
20 Passenger pretensioner
21 Occupancy detection unit
22 Fuse 14, passenger compartment fusebox
