ENGINE - V8

12-2-2

DESCRIPTION AND OPERATION

Description

General
The V8 petrol engine is a 4.4 litre, eight cylinder water cooled engine having two banks of four cylinders, arranged at
90 degrees to each other, with four valves per cylinder. The engine emissions comply with ECD3 (European
Commission Directive) and NAS LEV 2 legislative requirements. The engine comprises five main castings - two
cylinder heads, cylinder block, timing cover and the oil sump, all of which are manufactured from aluminium alloy.

Plastic rocker covers are fitted to the cylinder heads and, between the cylinder heads, is a plastic manifold intake
assembly. A plastic moulded acoustic cover is fitted over the upper engine to reduce engine generated noise.

The engine is supported, between cast mounting brackets and the front subframe, on two self-contained hydraulically
damped mounts.

Technical Features
The technical features include:



l

Four valves per cylinder

l

Single plenum chamber

l

Variable Camshaft Control (VCC) system

l

Double roller timing chain

l

Hydraulic Valve Adjusters (HVA)

l

Water Cooled Oil Cooler.

Engine Data
The technical data is detailed below

The cylinders are numbered as follows:

NOTE: Cylinders 4 and 8 are at the rear of the engine

Cylinder Block Components
The cylinder block components are described below:

Engine type

90

°

 V

Cylinders

8

Displacement 4398

ccm

Stroke/bore

82.7/92.0 mm

Maximum Power

210 kW (285 PS; 282 bhp) @ 5400

rev/min

Maximum Torque

440 Nm (324 lbf.ft) @ 3600 rev/min

Compression ratio

10: 1

Firing order

1–5–4–8–6–3–7–2

RH bank (bank 1)

Cylinders 1 to 4

LH bank (bank 2)

Cylinders 5 to 8
