BRAKESFront Brake Components
BRAKES
70-4
DESCRIPTION AND OPERATION
Front Brake Components
1 Brake pad wear detection sensor
2 Guide pin dust cover
3 Guide pin slider
4 Guide pin
5 Calliper carrier
6 Brake pad retainer
7 Mud shield retaining bolt
8 Brake disc
9 Brake disc retaining bolt
10 Mud shield
11 Calliper body
12 Piston seal
13 Piston dust cover
14 Mounting bolt
15 Bleed valve dust cap
16 Brake pads
17 Bleed valve
