Manifolds and Exhaust Systems – K1.8

TORQUE WRENCH SETTINGS

06-16

Manifolds and Exhaust Systems – K1.8

†

Tighten in sequence.

TORQUE DESCRIPTION

METRIC

IMPERIAL

Alternator bolts

45 Nm

33 lbf.ft

Alternator mounting bracket bolts

25 Nm

18 lbf.ft

Coil cover bolts

10 Nm

7.5 lbf.ft

Exhaust heatshield to manifold bolts

10 Nm

7.5 lbf.ft

Exhaust heatshield to manifold nut

25 Nm

18 lbf.ft

Exhaust front pipe to intermediate pipe nuts

60 Nm

44 lbf.ft

Exhaust front pipe to manifold nuts

60 Nm

44 lbf.ft

Exhaust manifold to cylinder head nuts

†

45 Nm

33 lbf.ft

Exhaust manifold heatshield to front pipe bolts

9 Nm

7 lbf.ft

Heated Oxygen (HO

2

S) Sensor

55 Nm

41 lbf.ft

Heatshield to alternator bracket:

⇒

 Nut

25 Nm

18 lbf.ft

⇒

 Bolts

10 Nm

7.5 lbf.ft

Inlet manifold to cylinder head nuts

†

17 Nm

12.5 lbf.ft

Intermediate pipe to tail pipe flange nuts

60 Nm

44 lbf.ft

RH coil bolts

10 Nm

7.5 lbf.ft

Tail pipe clamp nut

55 Nm

41 lbf.ft
