Heating and Ventilation

TORQUE WRENCH SETTINGS

06-32

Heating and Ventilation

TORQUE DESCRIPTION

METRIC

IMPERIAL

Air intake hose and bracket assembly to fuel burning heater bolts (Td4)

10 Nm

7.5 lbf.ft

Exhaust pipe clamp bolts (Td4)

5 Nm

3.5 lbf.ft

Fuel burning heater to body bolts (Td4)

8 Nm

6 lbf.ft

Fuel burning heater to mounting bracket bolts (Td4)

8 Nm

6 lbf.ft

Heater to fascia nuts

8 Nm

6 lbf.ft

Heater to bulkhead bolt

8 Nm

6 lbf.ft

Evaporator to bulkhead bolts

8 Nm

6 lbf.ft
