Brakes

TORQUE WRENCH SETTINGS

06-28

Brakes

1

 Use NEW bolts

TORQUE DESCRIPTION

METRIC

IMPERIAL

ABS ECU pipe unions

17 Nm

12 lbf.ft

ABS modulator to mounting bracket bolts

9 Nm

7 lbf.ft

ABS modulator mounting bracket to inner wing:

⇒

 Nuts

⇒

 Bolts

13 Nm

8 Nm

10 lbf.ft

6 lbf.ft

Bleed screw - front calipers

10 Nm

7.5 lbf.ft

Brake servo to bulkhead nuts

22 Nm

16 lbf.ft

EGR cooler to mounting bolts

25 Nm

18 lbf.ft

EGR pipe support bracket to engine lifting bracket bolts

25 Nm

18 lbf.ft

Front caliper brake hose banjo bolt

28 Nm

21 lbf.ft

Front caliper guide pin bolts

27 Nm

20 lbf.ft

Front caliper mounting bolts

100 Nm

74 lbf.ft

Front disc shield to hub screw

8.5 Nm

6.3 lbf.ft

Front disc to drive flange screws

5 Nm

3.7 lbf.ft

Fuel rail to support bracket bolt

10 Nm

7.5 lbf.ft

Handbrake cable to body and subframe bolts

22 Nm

16 lbf.ft

Handbrake cable retaining plate bolts

22 Nm

16 lbf.ft

Handbrake lever assembly to body bolts

22 Nm

16 lbf.ft

Hill Descent Control (HDC) switch bolt

5 Nm

3.5 lbf.ft

Master cylinder to servo nuts

25 Nm

18 lbf.ft

PAS oil cooler pipe bolts

10 Nm

7.5 lbf.ft

Primary and secondary brake pipe union nuts

17 Nm

12 lbf.ft

Rear wheel cylinder pipe union nut

17 Nm

12 lbf.ft

Rear wheel cylinder to backplate bolts

8 Nm

6 lbf.ft

Reservoir to master cylinder (LHD) Torx bolt

8 Nm

6 lbf.ft

Reservoir to master cylinder (LHD) Torx bolt

6 Nm

4.5 lbf.ft

Road wheel nuts

115 Nm

85 lbf.ft

Turbocharger intercooler pipe to support bracket bolt

10 Nm

7.5 lbf.ft

Turbocharger pipe to coolant rail bolt

25 Nm

18 lbf.ft

Vacuum pump bolts

1

22 Nm

16 lbf.ft

Vacuum reservoir to mounting bracket nut

10 Nm

7.5 lbf.ft
