LIFTING AND TOWING

08-2

Raising the front of a vehicle
Position the cup of the hydraulic arm under the
centre of the front body crossmember assembly.

Use jack to raise front road wheels to enable safety
stands to be  installed under the front end of each
longitudinal member.

Carefully lower jack until vehicle sits securely on
safety stands.

Before working on the underside of a vehicle re-
check the stability of the vehicle on the stands.

 Use the reverse procedure when removing a vehicle
from stands.

NOTE: For some repair operations it may be
necessary to use a jack to support the engine under
the sump. In this case, a block of wood should be
used on the jack to protect the sump.

Raising the rear of a vehicle
Position cup of hydraulic arm under the centre of the
rear subframe  crossmember at the position
identified by the embossed arrows.

Use jack to raise rear road wheels to enable safety
stands to be  installed under the rear ends of the
body longitudinal members.

Carefully lower jack until vehicle sits securely on
safety stands.

Before working on the underside of a vehicle, re-
check the  stability of the vehicle on the stands.

Use the reverse procedure when removing a vehicle
from stands.

Wheel-free lift
Locate the lifting pads under the ends of the body
longitudinal members. Raise the ramp to support the
weight of the vehicle, ensure the vehicle is secure on
the lifting pads, then raise the ramp to the required
height.

Towing

General
The vehicle has permanent four wheel drive. The
following instructions must be adhered to:

Towing the vehicle on all four wheels with driver
operating steering and brakes

l

Turn ignition key to position '1' to release
steering lock and then to position 'II' to enable
the brake lights, wipers and direction indicators
to be operated, if necessary.

l

 Select neutral in gearbox and ensure HDC (hill
descent control) is deselected.

l

Secure tow rope, chain or cable to towing eye.

l

Release the parking brake.

CAUTION: The brake servo and power assisted
steering system will not be functional without the
engine running. Greater pedal pressure will be
required to apply the brakes and the steering
system will require greater effort to turn the front
road wheels. The vehicle tow connection should
only be used under normal road conditions,
'snatch' recovery should be avoided.

Suspended tow by breakdown vehicle
Mark propeller shaft drive flanges and mating flanges
with identification lines to enable the propeller shaft
to be refitted in its original position.

Remove the propeller shaft fixings then remove the
shaft from  the vehicle.

CAUTION: To prevent vehicle damage, rear
propeller shaft MUST BE removed.
