Cooling system - KV6 Petrol

GENERAL DATA

04-19

Cooling system - Td4 Diesel

Cooling system - K1.8 Petrol

Cooling system - KV6 Petrol

Type

Pressurised, thermostatically controlled water / anti-freeze mixture

Cooling fans

Twin 11-blade axial flow electric, variable speed controlled via cooling
fan control unit by PWM signal from ECM.

Coolant pump

Radial flow impeller - mechanical

Thermostat

Wax element

Thermostat operating temperature:

⇒

 Initial opening

88

°

C

±

 2

°

C (190

°

F

±

 4

°

F)

Expansion tank cap relief valve - system operating
pressure

⇒

 Up to 03 MY

⇒

 03 MY onwards

140 kPa (1.43 bar, 20.3 lbf.in

2

)

100 kPa (1.0 bar, 14.5 lbf.in

2

)

Type

Pressurised, spill return, thermostatically controlled water/anti-freeze

Cooling fans

Twin 11-blade axial flow electric, variable speed controlled via cooling
fan control unit by PWM signal from ECM.

Coolant pump

Radial flow impeller - mechanical

Coolant pump drive ratio

1:1

Thermostat

Wax element

Thermostat operating temperature:

⇒

 Initial opening

85

°

C - 91

°

C (185

°

F - 196

°

F)

⇒

 Fully open - 9 mm (0.35 in.)

100

°

C (212

°

F)

Expansion tank cap relief valve - system operating
pressure

100 kPa (1.0 bar, 14.5 lbf.in

2

)

Type

Pressurised, spill return, thermostatically controlled water/ant-freeze

Cooling fans

Twin 11-blade axial flow electric, variable speed controlled via cooling
fan control unit by PWM signal from ECM.

Coolant pump

Radial flow - mechanical

Coolant pump drive ratio

0.93:1

Coolant pump output @ 1000 rev/min.

0.5 litres/sec. (0.875 imp. pts / sec.)

Thermostat

Wax element

Thermostat operating temperature:

⇒

 Initial opening

82

°

C

±

 2

°

C (180

°

F

±

 4

°

F)

⇒

 Fully open - 9 mm (0.35 in.)

102

°

C (216

°

F)

Expansion tank cap relief valve - system operating
pressure

100 kPa (1.0 bar, 14.5 lbf.in

2

)
