Brakes

GENERAL DATA

04-31

Brakes

Front disc brakes

Type

Pin-slider caliper with ventilated disc, self-adjusting

Disc diameter

262 mm (10.31 in)

Disc thickness:

⇒

 New

⇒

 Service limit

20.8 - 21.00 mm (0.818 - 0.826 in)
18.00 mm (0.708 in)

Disc run-out (maximum)

0.040 mm (0.0016 in), with wheel on

Pad minimum thickness

3.00 mm (0.118 in)

Rear drum brakes

Drum inside diameter

254 mm (10.00 in)

Drum wear limit

255.49 mm (10.059 in), discard drum

Lining minimum thickness

2.00 mm (0.079 in)

Drum ovality limit

0.012 mm (0.0005 in)

Master cylinder

Bore diameter

23.80 mm (0.937 in)

Brake servo

Servo boost ratio

4.5 : 1

Parking brake

Type

Mechanically operated via twin cables on rear drum brakes

Anti-lock braking system

Circuit type

Diagonal split, dual circuit, 4-sensor ABS

ABS type

TEVES MK20 with ABS, Hill Descent Control (HDC), Electronic
Traction Control (ETC) and Electronic Brakeforce Distribution (EBD)
