Ancillary drive belt - K1.8 with A/C (CHARGING AND STARTING)

CHARGING AND STARTING

86-1-2

ADJUSTMENTS

Ancillary drive belt - K1.8 with A/C

$% 86.10.05

Check

1. Disconnect battery earth lead.
2. Turn steering on RH lock.

3. Remove 3 bolts and remove splash shield.
4. Rotate crankshaft a sufficient number of turns

to check condition of drive belt. Renew a drive
belt that shows signs of wear, splitting or oil
contamination.

5. Check belt length, belt must be renewed before

indicator reaches RH end of slot.

6. Fit splash shield and secure with bolts.
7. Straighten steering.
8. Connect battery earth lead.
