FUEL DELIVERY SYSTEM - K SERIES KV6Fuel Delivery System Schematic
FUEL DELIVERY SYSTEM - K SERIES KV6
19-3-2
DESCRIPTION AND OPERATION
Fuel Delivery System Schematic
1 Fuel injector
2 Fuel tank
3 Swirl pot
4 Fuel filter
5 Pressure regulator valve
6 Non return valve
7 Fuel pump
