Cruise Control Interface ECU

CONTROL UNITS

DESCRIPTION AND OPERATION

86-3-7

Folding Door Mirror ECU (Some Markets)
In some markets folding door mirrors are installed and these are controlled by the folding door mirror ECU on vehicles
up to 2002 MY. The folding door mirror ECU is installed on the transmission tunnel, below the centre console.

On vehicles from 2002 MY, the folding door mirror ECU was replaced by a relay. The folding door mirror relay is
located on the front passenger side 'A' post.

Window Lift ECU
The window lift ECU is installed to provide one shot opening of the driver's door window. The window lift ECU is
installed on the driver's side A post, level with the lower edge of the fascia.


 +

 WINDOWS, DESCRIPTION AND OPERATION, Description.

Cruise Control Interface ECU
Where fitted, the cruise control interface ECU provides the interface between the cruise control operating system and
the cruise control switches on the steering wheel. The interface ECU is installed under the RH front seat.


 +

 ENGINE MANAGEMENT SYSTEM - SIEMENS, DESCRIPTION AND OPERATION, Cruise Control

Description.
