‹ PrevNext › The handbrake operates on both rear brakes via two handbrake cables, a cable equaliser and an int...
BRAKESHandbrake Component Layout
BRAKES
DESCRIPTION AND OPERATION
70-21
DESCRIPTION AND OPERATION
Handbrake Component Layout
1 Cable/Console bracket
2 Rear brake
3 Rear brake cable
4 Cable equaliser
5 Warning switch
6 Handbrake lever
7 Gaiter
‹ PrevNext › The handbrake operates on both rear brakes via two handbrake cables, a cable equaliser and an int...
