86 - ELECTRICALTACHOMETER
86
ELECTRICAL
36
REPAIR
SPEEDOMETER
Service repair no - 88.30.01
Remove
1. Remove instrument cowl.
See Instrument
cowl and illumination board
2. Remove speedometer trip reset button sleeve.
3. Remove instrument face plate.
4. Remove 4 screws securing speedometer,
remove speedometer.
Refit
5. Reverse removal procedure.
TACHOMETER
Service repair no - 88.30.21
Remove
See Circuit board
2. Remove instrument cowl.
See Instrument
cowl and illumination board
3. Remove speedometer trip reset button sleeve.
4. Remove instrument face plate.
5. Remove 3 screws securing tachometer to
binnacle, remove tachometer.
Refit
6. Reverse removal procedure.
