MANIFOLD AND EXHAUST SYSTEM

9

REPAIR

MANIFOLD CHAMBER GASKET - Mpi

Service repair no - 30.15.37

Remove

1. Disconnect battery negative lead.
2. Position absorbent cloth around fuel pipe to fuel

rail union. Loosen union to relieve pressure.
Re-tighten union.

3. Release clip and remove air cleaner to throttle

housing hose.

4. Disconnect stepper motor and throttle

potentiometer multiplugs.

5. Release clip and disconnect breather hose from

throttle housing.

6. Release throttle cable from abutment bracket.
7. Release throttle cable from cam. Remove

coolant bypass hose from throttle housing.

8. Disconnect fuel temperature sensor multiplug.
9. Release clip and disconnect brake servo hose

from manifold.
