On-Board Computer (page 5 of 5)

INSTRUMENTS

88-20

DESCRIPTION AND OPERATION

MFD Programming

MFD 'REMOTE CONTROL' Screen

1 Ensure that the ignition switch is in position I (AUX) or position II.
2 Press and hold the column stalk 'i' button for 3 seconds. 'REMOTE CONTROL' screen is displayed in the MFD

with all computer functions shown. Simultaneously, 'PROG' is displayed in the message centre.

3 To set the sequence, first deselect all functions using the RH control on the MFD panel. Select the function and

press the RH control to deselect that function. When deselected, the selection text will change colour.

4 Using the RH control, navigate to the first required computer function and press the RH control to select. When

selected, the selection text will change colour.

5 Continue selecting functions in the required order as required. If no functions are selected, there will be no

response from the 'i' button when pressed. All or just one function can be selected for display.

6 When desired selections are made, navigate to the 'memorise' function and press the RH control. The selected

functions are stored in their selected order in the instrument pack RAM. The instrument message centre then
displays the first selected function.

MID Programming

MID 'PROG 1' Display

1 Ensure that the ignition switch is in position I (AUX) or position II.
2 Press and hold the 'i' button for 3 seconds. 'PROG 1' appears in the MID with all computer functions assigned

to the keys.

M88 0351

Arrival time

Arrival time

Range

Distance

Limit

Clock

Date

Average speed

Average speed

Consump 2

Consump 2

Consump 1

Consump 1

Timer

Timer 2

Timer 2

Timer 1

Timer 1

memorise

REMOTE CONTROL

REMOTE CONTROL

TMC

30/07/2001

14:10

M88 0352

*

PROG   1

RANGE

SPEED

LIMIT

DIST ARR

CONSUM1

SET
