Liquid Crystal Display (LCD) (page 4 of 4)

INSTRUMENTS

88-12

DESCRIPTION AND OPERATION

Most messages, especially S, S1 and P messages are accompanied by a chime from the sounder to alert the driver
to their presence. At the end of a journey, a single chime precedes all end of journey messages.

For 3 minutes after the ignition is switched off, messages can be displayed using the check control RH button on the
instrument pack. If more than one message is present, the button must be pressed again to display the next message.
If no messages are present, 'CHECK CONTROL OK' will be displayed for as long as the button is pressed.

The messages are displayed in a language applicable to the vehicle market configuration and can be changed using
TestBook/T4. The following list shows the possible messages which can be displayed.

Message Centre Messages

PRE-HEATING

 SLOW

DOWN

FASTEN SEAT BELTS



SELECT NEUTRAL

TIME 8:59



CHECK BRAKE LIGHT

KEY IN IGNITION LOCK



ENGINE FAILSAFE PROG

RELEASE HANDBRAKE



TAILGATE OPEN

CHECK BRAKE FLUID



CHECK FRONT LIGHT

STOP!ENGINE OILPRESS



CHECK REAR LIGHT

COOLANT TEMPERATURE



CHECK DIP BEAM LIGHT

HDC TEMP. NOT AVAIL.



CHECK SIDE LIGHT

HDC INACTIVE



CHECK TAIL LIGHT

NO HDC, SLOW DOWN



CHECK FRONT FOGLIGHT

LIGHTS ON



CHECK REAR FOG LIGHT

SPEED LIMIT



CHECK NUMPLATE LIGHT

FUEL INJECT. SYSTEM



CHECK TRAILER LIGHT

AIR SUSP. INACTIVE
+ MAX 60 km/h
(Alternating)



CHECK MAINBEAM LIGHT

TRANSFERBOX NEUTRAL



TRANS. FAILSAFE PROG

HEADLIGHT DELAY



CHECK BRAKE PADS

TRANSMISS'N OVERHEAT



CHECK REVERSE LIGHT

EXTERNAL TEMPERATURE X

°

C/F



LOW SCREEN WASH

APPLY HANDBRAKE



CHECK AIR SYSTEM

EEPROM LCMC



ACCESS MAXIMUM 40 km/h

DOOR OPEN



OFF ROAD MAX 50 km/h

DSC INACTIVE



CHECK FUEL TANK CAP

HIGH RANGE



TYRECONTROL INACTIVE

LOW RANGE



TYRE DEFECT

CHECK COOLANT LEVEL



CHECK TYRE PRESSURE

MANUAL MODE



TYRE PRESS

SPORT MODE



SET TYRE PRESSURE

KEY BATTERY LOW



CHECK CONTROL OK

TRAILER MODE
