The following table shows the available warning lamps and indicates if they are subject to a bulb check illumination
and if they are self controlled or externally controlled.

Analogue Instruments
The analogue instruments are:

l

speedometer

l

tachometer

l

fuel level gauge

l

engine coolant temperature gauge.

Speedometer
The speedometer is an electrically driven, analogue instrument for displaying the vehicle speed. The pointer needle
is oil damped to prevent impacts on the vehicle wheels, causing deflection of the pointer needle.

The speedometer is driven by a square wave signal derived from the ABS ECU. The wheel speeds are measured by
sensors reading rotational speed from toothed targets on the hubs. These speeds are passed to the ABS ECU in the
form of pulsed signals. The ABS ECU is programmed that 48 pulses is equal to one revolution of the wheels and this
equates in distance to approximately 2 metres. The actual signal that drives the speedometer is a buffered signal sent
from the left hand rear speed sensor.

Warning Lamp

Illumination

Colour

Bulb Check

Self controlled

(S)/ Externally

controlled (E)

Gear selector lever 'P'

Green

No

E

Gear selector lever 'R'

Green

No

E

Gear selector lever 'N'

Green

No

E

Gear selector lever 'D'

Green

No

E

Gear selector lever '5'

Green

No

E

Gear selector lever '4'

Green

No

E

Gear selector lever '3'

Green

No

E

Gear selector lever '2'

Green

No

E

Gear selector lever '1'

Green

No

E

Transfer box low range

Green

No

E

Seat belt warning

Red

No

S/E

Brake assist warning

Amber

Yes

E

EBD warning

Red

Yes

E

General brake warning

Red

Yes

S

HDC

Green

Yes

E

Glow plug active

Amber

No

E

Low fuel level

Amber

Yes

S

Left direction indicator

Green

No

S/E

Right direction indicator

Green

No

S/E

Front fog lamps

Green

No

E

Rear fog lamps

Green

No

E

Headlamp main beam

Blue

No

E

Handbrake

Red

Yes

S

Battery charge indicator

Red

No

E

Dynamic stability control

Amber

Yes *

E

MIL / Service engine soon

Amber

No

E

Oil pressure

Red

No

E

ABS

Amber

Yes *

E

SRS

Red

No

E

Cruise control

Green

No

E

* = Bulb check performed by ECU, not instrument pack
