Sleep Mode

BODY CONTROL UNIT

86-3-4

DESCRIPTION AND OPERATION

Load Disconnection
The BCU supplies various electrical loads on the vehicle, such as the glovebox lamp, reading lamps, luggage
compartment lamps, etc., that can be switched on and remain on when the vehicle is parked. A central load
disconnection feature in the BCU ensures the battery is not discharged in the event these loads are switched on
continuously. The trigger time after the ignition is switched off is 16 minutes and is independent of the sleep mode
timer.

The BCU also disconnects the following loads while the engine cranks, to maximise the available power from the
battery:

l

Wipers

l

Washer pump

l

Headlamp cleaning

l

Window regulators

l

Sunroof.

If the one-touch function of a window or sunroof is active before the load disconnection, the function is not continued
when engine cranking stops.

Sleep Mode
To conserve power, the entire BCU goes into a 'sleep' mode 16 minutes after signal activity ceases and the ignition
is switched off. The typical current consumption of the BCU in sleep mode is 1.25 mA. In the sleep mode the BCU is
in a limited operational mode from which it can be awakened by certain relevant wake-up signals. After being
awakened, the BCU remains awake for 1 minute if no action is triggered. If an action is triggered, the BCU remains
awake for at least 16 minutes.

BCU

Automatic locking 2 minutes after
unlocking without opening

Active/ Inactive

BCU

Automatic locking after driving off

Active/ Inactive

Car

BCU

Automatic locking threshold speed
after driving off

2.5 to 17.5 mph (4 to 28 km/h) at
fixed intervals

Car

BCU

Driver's window one-touch open
function

Active/Inactive

Car

BCU

Driver's window one-touch close
function

Active/Inactive

Car

BCU

Front passenger window one-touch
open function

Active/Inactive

Car

BCU

Front passenger window one-touch
close function

Active/Inactive

Car

BCU

Rear windows one-touch open
function

Active/Inactive

Car

BCU

Rear windows one-touch close
function

Active/Inactive

Car

BCU

Window switch-off criterion

Europe
NAS

Car

BCU

Wiper reset (only without rain
sensor)

Active/Inactive

Car

BCU

Comfort function via remote control,
open all windows and sunroof

Active/Inactive

Car

BCU

Comfort function via remote control,
close all windows and sunroof

Active/Inactive

Car

BCU

Sunroof one-touch slide open
function

Active/Inactive

Car

BCU

Sunroof one-touch slide close
function

Active/Inactive

Car

BCU

Automatic locking after driving off

Active/ Inactive

Key

BCU

Remote central locking actuation

1st press open driver's door, 2nd
press open all doors
1st press open all doors

Key

 Control Unit

Function

Parameter

Memory Type
