VEHICLE DIMENSIONS

GENERAL SPECIFICATION DATA

25

INFORMATION

VEHICLE DIMENSIONS

Dimensions

Overall length (including spare wheel)

4538 mm

.............................

Overall length (including tow hitch)

4581 mm

..................................

Overall width

2189 mm

....................................................................

Overall height

1914 mm

...................................................................

Wheelbase

2540 mm

.......................................................................

Track front/rear

1486 mm

.................................................................

Width between wheel boxes

1080 mm

............................................

Seating capacity

5 to 7

...............................................................

Performance

Tyre size fitted

205 R16 radial

..................................................................

Tyre size fitted

235/70 R16 radial

..................................................................

Max. gradient (EEC kerb weight)

45

°

.....................................

Approach angle (EEC kerb weight)

35

°

..................................

Departure angle with tow hitch (EEC kerb weight)

20

°

...........

Departure angle without tow hitch
(EEC kerb weight)

29

°

............................................................

Ramp break over angle

33

°

....................................................

Min. ground clearance (unladen)

204 mm

.....................................

Wading depth

500 mm

...................................................................

Towing weights

On road

Off road

Unbraked trailers

750 kg

..............................................................

500 kg

Trailers with overrun brakes - Mpi

2750 kg

....................................

1000 kg

Trailers with overrun brakes - V8i & Tdi

3500 kg

...........................

1000 kg

4 wheel trailers with coupled brakes
(FULLY BRAKED)*

4000 kg

..........................................................

1000 kg

NOTE: * Only applies to vehicles modified to accept coupled brakes.

NOTE: All weight figures are subject to local restrictions.
