TRANSMISSION - Mpi

04

GENERAL SPECIFICATION DATA

24

INFORMATION

FUEL SYSTEM - Mpi

Electronic fuel injection data

See ENGINE TUNING DATA, Information, Engine

............................................

- Mpi - 2.0 Litre

Fuel Pump:
Make/Type

A.C. Rochester/Electric immersible

.......................................................................

Pump pressure

3.2 bar

.................................................................

Delivery at 3 bar pressure & 12V (min)

64 litre/h

............................

Regulated pressure range

3.0 æ 0.2 bar

................................................

Fuel pump delivery pressure

2.3 - 2.5 kgf/cm

2

............................................

Fuel filter

Bosch in-line filter ’canister’ type

..........................................................................

COOLING SYSTEM - Mpi

Pressure cap

15lbf/in

2

(1.03 bar) (system pressure)

....................................................................

Thermostat

88 ˚C

.......................................................................

CLUTCH - Mpi

Type

Diaphragm spring, hydraulically operated

.................................................................................

Adjustment

Self adjusting

.......................................................................

Clutch plate diameter

215.13 mm

.......................................................

TRANSMISSION - Mpi

Manual gearbox

Type R380

Single helical constant mesh

.......................................................................

Speeds

5 forward 1 reverse all synchromesh

.............................................................................

Transfer box

Type LT230T

Two speed reduction on main gearbox output. Front

....................................................................

and rear drive permanently engaged via a lockable
differential

Overall ratios (final drive):

In high transfer

In low transfer

Fifth

4.146:1

..................................................................................

9.761:1

Fourth

4.989:1

...............................................................................

11.746:1

Third

7.518:1

.................................................................................

17.701:1

Second

11.479:1

.............................................................................

27.109:1

First

17.884:1

..................................................................................

42.109:1

Reverse

18.463:1

............................................................................

43.472:1
