INSTRUMENT LIGHTING - Wiring diagram

Wiring diagram

COMPONENTS

Component code	Name	Assembly reference
B2	Junction unit under dashboard	5505A
C16	Air conditioning earth
C30	Left rear earth
C31	Rear right earth
D8	Dashboard / air conditioner - heater connection
D8	Front / air conditioning - heater coupling
D20	/Rear dashboard coupling
D30	Rear coupling for /front door. driver's side
D31	Front passenger door/ rear coupling.
D97	Short circuiting coupling
E50	Instrument panel	5560B
G10	Front courtesy light	7040E
G45	Air conditioning / heater controls light	5020B
H35	Switches on tunnel	7040L
H44	Driver's side front door electric window controls	7005M
H44	Electric window controls in driver's front door	7005M
H50	Electric window switch on .front passenger door	7005M
H80	Climate control system controls	5040D
H90	Switch control unit	5505A
M1	Body computer	5505A
M66	Driver's door control unit	5505A
M67	Passenger door control unit	5505A
P20	Radio	5570T
P50	Cigar lighter/current socket	7065C
P50	Cigarette lighter/power socket	7065C
