P20 Radio

Make

Lancia

Model

Ypsilon Factory Service Manual

Year

2003–2011

Section

Various consumers › P20 Radio

Connectors and pin-outsP20 Radio

P20 Radio

P20A – Facia

Wiring	Colour
20 FACIA

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
2		H		D97F	7
3		BS		B2H	17
4	1.5	R		B2H	7
5		RM		D20B	11
6		G		D20B	10
8	2.5	N		C20A	3

BOSE System

Wiring	Colour
20 FACIA

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1		NS		B2H	5
2		H		D97F	7
3		BS		B2H	17
4	1.5	R		B2H	7
5		RM		D20B	11
6		G		D20B	10
8	2.5	N		C20A	3

P20B – Facia

Wiring	Colour
20 FACIA

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	1.5	AG		D20B	5
2	1.5	AR		D20B	6
3	1.5	SN		D20B	9
4	1.5	NZ		D20B	8
5	1.5	RN		D20B	1
6	1.5	BN		D20B	2
7	1.5	CN		D20B	3
8	1.5	CB		D20B	4

P20C – Facia

BOSE System

Wiring	Colour
20 FACIA

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
6		H		D20A	1

P20E – Parking sensor braid

Sound System with CD player

Wiring	Colour
74 PARKING SENSOR BRAID

21 General
