Brake lights - wiring diagram

Make

Fiat

Model

Doblò Factory Service Manual

Year

2000–2010

Section

Exterior lighting › Brake lights - wiring diagram

Wiring diagrams and electrical functionsBrake lights - wiring diagram

BRAKE LIGHTS - WIRING DIAGRAM

1.2 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V, 1.9 DIESEL · from 10/2000, up to 10/2000

Wiring diagram

COMPONENTS

Component code	Name	Assembly reference
B1	Engine compartment junction unit
B1	Engine compartment junction unit	Op. 1004B POWER UNIT ASSEMBLY
B1	Engine compartment junction unit	Op. 5505A MULTI-FUNCTION COMPONENTS
B2	Junction unit under dashboard
B2	Junction unit under dashboard	Op. 5505A MULTI-FUNCTION COMPONENTS
C15	Facia earth, driver''s side
C30	Left rear earth
D85	Tailgate rear seal/
D85	Tailgate/ rear coupling
F30	Rear left light cluster	Op. 5540A LIGHTING
F31	Rear right light cluster	Op. 5540A LIGHTING
F40	Additional (third brake light)	Op. 5550D BRAKE AND REVERSING LIGHTS
I30	Brake pedal switch
I30	Brake pedal switch	Op. 5550D BRAKE AND REVERSING LIGHTS
M1	Body computer
M1	Body computer	Op. 5505A MULTI-FUNCTION COMPONENTS

1.2 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V, 1.9 DIESEL · from 12/03

Wiring diagram

COMPONENTS

Component code	Name	Assembly reference
B1	Engine compartment junction unit
B1	Engine compartment junction unit	Op. 1004B POWER UNIT ASSEMBLY
B1	Engine compartment junction unit	Op. 5505A MULTI-FUNCTION COMPONENTS
B2	Junction unit under dashboard
B2	Junction unit under dashboard	Op. 5505A MULTI-FUNCTION COMPONENTS
C15	Facia earth, driver''s side
C30	Left rear earth
D85	Tailgate rear seal/
D85	Tailgate/ rear coupling
F30	Rear left light cluster	Op. 5540A LIGHTING
F31	Rear right light cluster	Op. 5540A LIGHTING
F40	Additional (third brake light)	Op. 5550D BRAKE AND REVERSING LIGHTS
I30	Brake pedal switch
I30	Brake pedal switch	Op. 5550D BRAKE AND REVERSING LIGHTS
M1	Body computer
M1	Body computer	Op. 5505A MULTI-FUNCTION COMPONENTS

1.4 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V · from 12/03 · MY 2005

Components

Component code	Description	Reference to the assembly
B001	JUNCTION UNIT	Op. 5505A MULTI-FUNCTION COMPONENTS
B2	JUNCTION UNIT UNDER DASHBOARD	Op. 5505A MULTI-FUNCTION COMPONENTS
C15	DASHBOARD EARTH, DRIVER''S SIDE
C030	LEFT REAR EARTH
D085	TAILGATE/REAR SEAL
E50	INSTRUMENT PANEL	Op. 5560B ANALOGUE CONTROL PANEL
F030	LEFT REAR LIGHT CLUSTER	Op. 5540A LIGHTING
F031	RIGHT REAR LIGHT CLUSTER	Op. 5540A LIGHTING
F040	ADDITIONAL REAR LIGHT (THIRD BRAKE LIGHT)	Op. 5550D BRAKE AND REVERSING LIGHTS
H001	IGNITION SWITCH	Op. 5520A IGNITION SWITCH
I030	BRAKE PEDAL SWITCH	Op. 5550D BRAKE AND REVERSING LIGHTS
M001	BODY COMPUTER	Op. 5505A MULTI-FUNCTION COMPONENTS

19 Electrical
