I030 brake pedal switch

Make

Fiat

Model

Doblò Factory Service Manual

Year

2000–2010

Section

Switches › I030 brake pedal switch

Connectors and pin-outsI030 brake pedal switch

I030 BRAKE PEDAL SWITCH

1.6 16v · from 12/03 · BIPOWER, MY 2005

Wiring	Colour
See 12 FRONT	BIANCO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
2	0,5	C		See B002A JUNCTION UNIT UNDER DASHBOARD (FRONT)	14
4	0,5	CN		See B002A JUNCTION UNIT UNDER DASHBOARD (FRONT)	15

1.4 8v, 1.3 JTD 16V, 1.9 JTD 8V · from 12/03 · MY 2005

Wiring	Colour
See 12 FRONT	BIANCO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	0,5	M		See D004B FRONT/ENGINE JUNCTION (FRONT)	E
2	0,5	C		See B002A JUNCTION UNIT UNDER DASHBOARD (FRONT)	14
3	0,5	V		See B002A JUNCTION UNIT UNDER DASHBOARD (FRONT)	18
4	0,5	MG	X	See D004B FRONT/ENGINE JUNCTION (FRONT)	K
				See B002A JUNCTION UNIT UNDER DASHBOARD (FRONT)	15

I30 – Front

1.2 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V, 1.9 DIESEL

Wiring	Colour
See 12 FRONT	nero

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	0,5	C		See B2A JUNCTION UNIT UNDER DASHBOARD ( FRONT )	14
2	0,5	N		See B2A JUNCTION UNIT UNDER DASHBOARD ( FRONT )	15

Wiring	Colour
See 12 FRONT	nero

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
2	0,5	C		See B2A JUNCTION UNIT UNDER DASHBOARD ( FRONT )	14
4	0,5	N		See B2A JUNCTION UNIT UNDER DASHBOARD ( FRONT )	15

Wiring	Colour
See 12 FRONT	nero

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	0,5	M		See D4A FRONT/ENGINE COUPLING ( FRONT )
2	0,5	C		See B2A JUNCTION UNIT UNDER DASHBOARD ( FRONT )	14
3	0,5	V		See B2A JUNCTION UNIT UNDER DASHBOARD ( FRONT )	18
4	0,5	MG	X	See D4B FRONT/ENGINE COUPLING ( CONNECTORS )
				See B2A JUNCTION UNIT UNDER DASHBOARD ( FRONT )	15
