P055 heated rearscreen
- Make
- Alfa Romeo
- Model
- 159 Factory Service Manual
- Year
- 2005–2011
- Section
- Various consumers › P055 heated rearscreen
Connectors and pin-outsP055 heated rearscreen
P055 HEATED REARSCREEN
P055A – Tailgate
| Wiring | Colour |
|---|---|
| See 27 TAILGATE | NERO |
| Pin | Cable | Destination | |||
|---|---|---|---|---|---|
| Sec. | Colour | Node | Connect. | Pin | |
| 1 | 4 | R | See D085B (TAILGATE) | 1 | |
P055A – Rear
| Wiring | Colour |
|---|---|
| See 25 REAR | BIANCO |
| Pin | Cable | Destination | |||
|---|---|---|---|---|---|
| Sec. | Colour | Node | Connect. | Pin | |
| 1 | 4 | RN | See B002D JUNCTION UNIT UNDER DASHBOARD (REAR) | 15 | |
P055B – Tailgate
| Wiring | Colour |
|---|---|
| See 27 TAILGATE | NERO |
| Pin | Cable | Destination | |||
|---|---|---|---|---|---|
| Sec. | Colour | Node | Connect. | Pin | |
| 1 | 4 | N | See D085B (TAILGATE) | 2 | |
P055B – Rear
| Wiring | Colour |
|---|---|
| See 25 REAR | BIANCO |
| Pin | Cable | Destination | |||
|---|---|---|---|---|---|
| Sec. | Colour | Node | Connect. | Pin | |
| 1 | 4 | N | See C032 REARSCREEN EARTH | 1 | |
