86 - ELECTRICALSPEAKERS AND AMPLIFIER PACK, REAR DOOR
background image

86

ELECTRICAL

24

REPAIR

SPEAKERS AND AMPLIFIER PACK, REAR DOOR

Service repair no - 86.50.36

Remove

1. Disconnect battery negative lead.
2. Remove securing screws and withdraw speaker

grille.

3. Remove securing screws and withdraw speaker

trim.

4. Remove securing screws ease speaker and

amplifier pack away from door panel, disconnect
multiplug and withdraw assembly.

5. Disconnect speaker plug from amplifier remove

securing screws and detach amplifier.

Refit

6. Reverse removal procedure.
