DIRECTION INDICATOR, TAIL LIGHT BULBS.

86

ELECTRICAL

18

REPAIR

REAR LIGHTS, BUMPER MOUNTED

Service repair no - 86.41.42

Remove

1. From behind bumper disconnect light plugs.
2. Unscrew two retaining nuts and remove light unit

from bumper.

Refit

3. Reverse removal procedure.

NOTE: The black lead plug fits into the
direction indication light, the white lead
plugs into the tail light, the bulb holder

being colour coded red.

DIRECTION INDICATOR, TAIL LIGHT BULBS

Service repair no - 86.41.43

Remove

1. Turn bulb holder anti-clockwise to release from

light unit.

2. Push and twist the bulb to remove.

Refit

3. Reverse removal procedure.
