41 - TRANSFER GEARBOXREAR OUTPUT DRIVE ASSEMBLY

41

TRANSFER GEARBOX

2

DESCRIPTION AND OPERATION

REAR OUTPUT DRIVE ASSEMBLY

1. Rear output shaft
2. Joint sealant
3. Speedometer drive housing
4. Speedometer drive pinion assembly
5. Speedometer worm drive
6. Spacer

7. Ball bearing
8. Circlip
9. Oil seal

10. Oil shield
11. Rear output flange
12. Sealing washer
