STEERING

04

GENERAL SPECIFICATION DATA

10

INFORMATION

COOLING SYSTEM 3.9 V8i

System type

Pressurised, spill return, thermostatically controlled

.....................................................................

water and anti-freeze mixture. Pump assisted thermo
syphon. Coolant radiator combined with oil cooler.

Fan and viscous coupling assembly

11 blade axial flow 433mm diameter.

................................

Pump type

Centifugal, impellor, belt driven.

........................................................................

Thermostat opening

88 degrees.

.........................................................

Expansion tank cap pressure

15 p.s.i. (system pressure).

...........................................

STEERING

Power steering box

Make/type

Adwest Varamatic - worm and roller box

........................................................................

Ratio

Variable: straight ahead 19.3:1 on lock 14.3:1

.................................................................................

Steering wheel turns, lock-to-lock

3.375

....................................

Steering pump

Make/type -V8i

ZF - Unicorn

.................................................................

Make/type - Mpi & Tdi

Hobourn-Eaton series 500

......................................................

Steering geometry

Steering wheel diameter

405mm

..................................................

Steering wheel diameter airbag model

400mm

.............................

Toe-out measurement

0 to 2mm toe out

......................................................

Toe-out included angle

0˚ to 0˚ 16’

.....................................................

Camber angle

0˚

..................................................................

Check with vehicle in static

..............

unladen condition, that is, vehicle
with water,

Castor angle

3˚

.....................................................................

oil and five gallons of fuel. Rock

..............

the vehicle up and down at the
front to allow

Swivel pin inclination static

7˚

...............................................

it to take up a position

..............
