ELECTRICAL

GENERAL SPECIFICATION DATA

13

INFORMATION

AIR CONDITIONING

System

Nippon Denso

.............................................................................

Compressor

Nippon Denso 10 PA 17

.....................................................................

Refrigerant

R134a

.......................................................................

Charge quantity

0.9Kg

................................................................

Charge quantity with rear air conditioning

1.15Kg

........................

WIPER MOTORS

Tailgate wiper motor

Make/type

IMOS (non-serviceable)

........................................................................

Running current, wet screen at 20

°

C ambient

1.0 to 2.8 amps

.................

Wiper speed, wet screen at 20

°

C ambient

37 to 43 cycles per minute

.......................

Windscreen wiper motor

Make/type

Delco AMR 1514/5

........................................................................

Running current (Link disconnected)

1.5 amps at 39 to 45 rev/min (normal speed)

...............................

Rotary link speed

60 to 73 rev/min (high speed)

.............................................................

ELECTRICAL

System

12 volt, negative ground

.............................................................................

Battery

Make/type - basic

Land Rover Parts and Equipment/Lucas maintenance

.............................................................

free 9-plate-YGD 10017

Make/type - heavy duty

Land Rover Parts and Equipment/Lucas maintenance

....................................................

free 14-plate-YGD 10015

Generator

Manufacturer

Magnetti Marelli

....................................................................

Type

A127i 100amp

.................................................................................

Polarity

Negative ground

.............................................................................

Brush length

New

17 mm

.........................................................................

Worn, minimum free protrusion from moulding

5 mm

.......

Brush spring pressure flush with moulding

1.3N to 2.7N

......................

Regulator voltage

13.6 to 14.4 volts

.............................................................

Nominal output

Generator speed

6000 rev/min

.....................................................

Control voltage

14 volt

........................................................

Amp

100 amp

.........................................................................
