CLUTCH - 300 Tdi

04

GENERAL SPECIFICATION DATA

20

INFORMATION

Lubrication

System

Wet sump, pressure fed

.............................................................................

Pressure, engine warm at normal operating speeds

25 - 55lbf/in

2

= 1,76 - 3,87Kgf cm

2

........

Oil pump:

- Type

G-rotor integral with front cover.

......................................................................

- Drive

off crankshaft nose

.....................................................................

Oil pressure relief valve

Non-adjustable

....................................................

Relief valve spring:
- Full length

51,6mm

......................................................................

- Compressed length at 7.71Kg load

31mm

................................

Oil filter

Screw-on disposable canister

.............................................................................

Engine oil cooler

Combined with coolant radiator and intercooler

...............................................................

FUEL SYSTEM - 300 Tdi

Fuel lift pump type

Mechanical with hand primer

............................................................

Fuel lift pump pressure

42 - 55 kpa at 1800 rpm

.....................................................

Fuel filter

Paper element in disposable canister

..........................................................................

Air cleaner

Paper element type

........................................................................

COOLING SYSTEM - 300 Tdi

System type

Pressurised, spill return, thermostatically controlled

.....................................................................

water and anti freeze mixture. Pump assisted thermo
syphon. Coolant radiator combined with oil cooler and
turbo intercooler.

Cooling fan

11 blade axial flow 433 mm diameter. 1.29:1 drive

.......................................................................

ratio. Viscous coupling.

Pump type

Centrifugal, impellor, belt driven.

........................................................................

Thermostat opening

88

°

.........................................................

Expansion tank cap pressure

15lbf/in

2

= 1,06Kgf cm

2

(system pressure)

...........................................

CLUTCH - 300 Tdi

Type

Valeo diaphragm spring

.................................................................................

Centre plate diameter

235 mm

.......................................................

Facing material

Verto F202 grooved

.................................................................

Release bearing

Ball journal

...............................................................
