Wiring diagrams and electrical functionsBRAKE LIGHTS - Wiring diagram
BRAKE LIGHTS - Wiring diagram
Wiring diagram
COMPONENTS
| Component code | Name | Assembly reference |
|---|---|---|
| B1 | Engine compartment junction unit | 5505A |
| B2 | Junction unit under dashboard | 5505A |
| C20 | Passenger side dashboard earth | |
| C30 | Left rear earth | |
| C31 | Rear right earth | |
| E50 | Instrument panel | 5560B |
| F30 | Rear left light cluster | 5540A |
| F31 | Rear right light cluster | 5540A |
| F40 | Additional ("third brake light") | 5550D |
| F40 | Additional ('third brake light') | 5550D |
| H1 | Ignition switch | 5520A |
| I30 | Brake pedal switch | 5550D |
| M1 | Body computer | 5505A |
