H1 Ignition switch

Make

Lancia

Model

Ypsilon Factory Service Manual

Year

2003–2011

Section

Manual electric controls › H1 Ignition switch

Connectors and pin-outsH1 Ignition switch

H1 Ignition switch

H1A – Front

1.4 16v, 1.3 JTD · Smart gearbox

Wiring	Colour
12 FRONT	BIANCO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	1.5	C		B1A	30
2	1.5	R		B1A	31
3	1.5	M		D97C	6

All versions

Wiring	Colour
12 FRONT	BIANCO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	1.5	C		B1A	30
2	1.5	R		B1A	31
3	1.5	M		B1A	18

H1B – Facia

Wiring	Colour
20 FACIA	BIANCO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	1.5	A		B2H	1
2	1.5	L		B2H	11
