C20 Passenger side dashboard earth

Make

Lancia

Model

Ypsilon Factory Service Manual

Year

2003–2011

Section

Earths › C20 Passenger side dashboard earth

Connectors and pin-outsC20 Passenger side dashboard earth

C20 Passenger side dashboard earth

C20A – Facia

Wiring	Colour
20 FACIA	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	1.5	N		B2H	10
3	2.5	N		P20A	8
3	2.5	N		P20A	8
5		NZ		D47	6
6		NZ		9
7		N		D8B	2
12		NZ		12

C20B – Facia

Wiring	Colour
20 FACIA	BIANCO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1		N		M1I	8
2		NZ		H5C	9
5		NZ		M1I	9
6		NZ		H90A	5

C20C – Rear

Wiring	Colour
25 REAR	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1		NZ		K125	3
2		NV		M84	12
3		NZ		K125	4
5		N		H60	1
6		NZ		10

C20D – Rear

Wiring	Colour
25 REAR

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	2.5	NL		D31	4
1	2.5	NL		D30	4
