D47 Clock spring coupling

Make

Lancia

Model

Ypsilon Factory Service Manual

Year

2003–2011

Section

Intermediate couplings › D47 Clock spring coupling

Connectors and pin-outsD47 Clock spring coupling

D47 Clock spring coupling

Wiring	Colour
20 FACIA	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1		NV		D1	3
3		NS		M1H	24
4		BS		M1H	25
5		LB		B2H	12
6		NZ		C20A	5
9		V		M60A	18
10		HN		M60A	17
11		MB		M60A	21
12		M		M60A	22
