H001 Ignition switch

Make

Lancia

Model

Thesis Factory Service Manual

Year

2002–2009

Section

Manual electrical controls › H001 Ignition switch

Connectors and pin-outsH001 Ignition switch

H001 Ignition switch

H001A – Front

3.2 V6

Wiring	Colour
12 FRONT

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin

2.4 20V

Wiring	Colour
12 FRONT

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1	100,5	C		B001A	30
2	100,5	R		B001A	31
3	100,5	M		D097A	4

2.4 JTD 10V

Wiring	Colour
12 FRONT

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1	100,5	C		B001A	30
2	100,5	R		B001A	31
3	100,5	M		D097A	4

3.0 V6

Wiring	Colour
12 FRONT

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1	100,5	C		B001A	30
2	100,5	R		B001A	31
3	100,5	MN		D097B	7

2.4 JTD 20V

Wiring	Colour
12 FRONT

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1	100,5	C		B001A	30
2	100,5	R		B001A	31
3	100,5	M		D097A	4

2.0 TB

Wiring	Colour
12 FRONT

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1	100,5	C		B001A	30
2	100,5	R		B001A	31
3	100,5	M		D097A	4

2.4 20V

Wiring	Colour
12 FRONT

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1	100,5	C		B001A	30
2	100,5	R		B001A	31
3	100,5	MN		D097B	7

2.4 JTD 20V

Wiring	Colour
12 FRONT

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1	100,5	C		B001A	30
2	100,5	R		B001A	31
3	100,5	MN		D097B	7

H001B – Dashboard

2.4 20V

Wiring	Colour
20 DASHBOARD

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1	100,5	A		B002H	1
2	100,5	L		B002H	11
3	0,5	N		D020	43
4	0,5	LS		D020	22

2.0 TB

Wiring	Colour
20 DASHBOARD

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1	100,5	A		B002H	1
2	100,5	L		B002H	11
3	0,5	N		D020	43
4	0,5	LS		D020	22

2.4 JTD 10V

Wiring	Colour
20 DASHBOARD

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1	100,5	A		B002H	1
2	100,5	L		B002H	11
3	0,5	N		D020	43
4	0,5	LS		D020	22

3.0 V6

Wiring	Colour
20 DASHBOARD

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1	100,5	A		B002H	1
2	100,5	L		B002H	11
3	0,5	N		D020	43
4	0,5	LS		D020	22
