Lancia Thesis Factory Service Manual (2002-2009)21 · Connectors and pin-outs

21 · General

A001 Battery

Make: Lancia
Model: Thesis Factory Service Manual
Year: 2002–2009
Section: Starting - recharging › A001 Battery

‹ Prev Right front seat backrest bridge Next › A005 Contact board

Connectors and pin-outsA001 Battery

A001 Battery

A001A – Battery positive

2.0 TB

A001 Battery

Wiring	Colour
41 BATTERY POSITIVE

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1				B099G	1

2.4 20V

A001 Battery

Wiring	Colour
41 BATTERY POSITIVE

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1				B099G	1

2.4 JTD 10V

A001 Battery

Wiring	Colour
41 BATTERY POSITIVE

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1				B099G	1

3.0 V6

A001 Battery

Wiring	Colour
41 BATTERY POSITIVE

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1				B099G	1

A001B – Battery negative

2.4 20V

A001 Battery

Wiring	Colour
40 BATTERY NEGATIVE

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1	35	N		C001	1

2.0 TB

A001 Battery

Wiring	Colour
40 BATTERY NEGATIVE

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1	35	N		C001	1

2.4 JTD 10V

A001 Battery

Wiring	Colour
40 BATTERY NEGATIVE

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1	35	N		C001	1

3.0 V6

A001 Battery

Wiring	Colour
40 BATTERY NEGATIVE

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1	35	N		C001	1
