C020 Passenger dashboard earth

Make

Lancia

Model

Thesis Factory Service Manual

Year

2002–2009

Section

Earths › C020 Passenger dashboard earth

Connectors and pin-outsC020 Passenger dashboard earth

C020 Passenger dashboard earth

2.4 20V

Wiring	Colour
25 REAR

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1	0,5	N		D020	43
2	0,5	N		D031	1
3	0,35	NZ		G058	2
4	0,5	N		D036	19
6	0,5	N		D071A	L
8	200,5	N		D031	4
9	200,5	N		D071A	F
14	0,5	N		M064	10

2.0 TB

Wiring	Colour
25 REAR

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1	0,5	N		D020	43
2	0,5	N		D031	1
3	0,35	NZ		G058	2
4	0,5	N		D036	19
6	0,5	N		D071A	L
8	200,5	N		D031	4
9	200,5	N		D071A	F
14	0,5	N		M064	10

2.4 JTD 10V

Wiring	Colour
25 REAR

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1	0,5	N		D020	43
2	0,5	N		D031	1
3	0,35	NZ		G058	2
4	0,5	N		D036	19
6	0,5	N		D071A	L
8	200,5	N		D031	4
9	200,5	N		D071A	F
14	0,5	N		M064	10

3.0 V6

Wiring	Colour
25 REAR

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1	0,5	N		D020	43
2	0,5	N		D031	1
3	0,35	NZ		G058	2
4	0,5	N		D036	19
6	0,5	N		D071A	L
8	200,5	N		D031	4
9	200,5	N		D071A	F
14	0,5	N		M064	10
