Wiring diagrams and electrical functions TRIP COMPUTER - Wiring diagram
TRIP COMPUTER - Wiring diagram
1.1, 1.2 8v
Wiring diagram
COMPONENTS
Component code Name Assembly reference C20 Passenger side dashboard earth D4 Front / engine coupling D4 Front/engine connection E50 Instrument panel 5560B H5 Steering column switch unit 5550A K46 Rpm sensor K46 Rpm sensor 1060G K46 Rpm sensor 5510C K84 Speedometer sensor M1 Body computer 5505A M10 Engine management control unit M10 Engine management control unit 1056B M10 Engine management control unit 1060G M50 ABS control unit 3340A N40 Fuel pump and sender unit 1040A
1.2 8v · Smart gearbox
Wiring diagram
COMPONENTS
Component code Name Assembly reference C20 Passenger side dashboard earth D4 Front / engine coupling D4 Front/engine connection E50 Instrument panel 5560B H5 Steering column switch unit 5550A K46 Rpm sensor K46 Rpm sensor 1060G K46 Rpm sensor 5510C K84 Speedometer sensor M1 Body computer 5505A M10 Engine management control unit M10 Engine management control unit 1056B M10 Engine management control unit 1060G M50 ABS control unit 3340A N40 Fuel pump and sender unit 1040A
1.3 JTD 16v
Wiring diagram
COMPONENTS
Component code Name Assembly reference C20 Passenger side dashboard earth D4 Front / engine coupling D4 Front/engine connection E50 Instrument panel 5560B H5 Steering column switch unit 5550A K46 Rpm sensor K46 Rpm sensor 1060G K46 Rpm sensor 5510C K84 Speedometer sensor M1 Body computer 5505A M10 Engine management control unit M10 Engine management control unit 1056B M10 Engine management control unit 1060G M50 ABS control unit 3340A N40 Fuel pump and sender unit 1040A
