Wiring diagrams and electrical functionsInstrument panel - wiring diagram
INSTRUMENT PANEL - WIRING DIAGRAM
Components
| Component code | Description | Reference to the assembly |
|---|---|---|
| B001 | JUNCTION UNIT | Op. 5505A MULTI-FUNCTION COMPONENTS |
| B2 | JUNCTION UNIT UNDER DASHBOARD | Op. 5505A MULTI-FUNCTION COMPONENTS |
| C10 | LEFT FRONT EARTH | |
| C15 | DASHBOARD EARTH, DRIVER''S SIDE | |
| D004 | FRONT/ENGINE COUPLING | |
| E50 | INSTRUMENT PANEL | Op. 5560B ANALOGUE CONTROL PANEL |
| H001 | IGNITION SWITCH | Op. 5520A IGNITION SWITCH |
| I040 | HANDBRAKE SWITCH | Op. 5550D BRAKE AND REVERSING LIGHTS |
| K025 | BRAKE FLUID LEVEL SENSOR (SWITCH) | Op. 3330D BRAKE VACUUM SYSTEM |
| K30 | ENGINE OIL PRESSURE SENSOR (SWITCH) | |
| K36 | ENGINE COOLANT TEMPERATURE SENSOR/SENDER UNIT | |
| K46 | RPM SENSOR | |
| K84 | SPEEDOMETER SENSOR | |
| M001 | BODY COMPUTER | Op. 5505A MULTI-FUNCTION COMPONENTS |
| M010 | ENGINE MANAGEMENT ECU | |
| M19 | METHANE INJECTION CONTROL UNIT | |
| N040 | FUEL PUMP AND LEVEL GAUGE |
Components
| Component code | Description | Reference to the assembly |
|---|---|---|
| B001 | JUNCTION UNIT | Op. 5505A MULTI-FUNCTION COMPONENTS |
| B2 | JUNCTION UNIT UNDER DASHBOARD | Op. 5505A MULTI-FUNCTION COMPONENTS |
| C10 | LEFT FRONT EARTH | |
| C15 | DASHBOARD EARTH, DRIVER''S SIDE | |
| D004 | FRONT/ENGINE COUPLING | |
| D20 | DASHBOARD/REAR COUPLING | |
| D29 | ENGINE CABLES/ENGINE SERVICES CABLE COUPLING | |
| D30 | REAR/DRIVER''S FRONT DOOR COUPLING | |
| E50 | INSTRUMENT PANEL | Op. 5560B ANALOGUE CONTROL PANEL |
| H001 | IGNITION SWITCH | Op. 5520A IGNITION SWITCH |
| I040 | HANDBRAKE SWITCH | Op. 5550D BRAKE AND REVERSING LIGHTS |
| K025 | BRAKE FLUID LEVEL SENSOR (SWITCH) | Op. 3330D BRAKE VACUUM SYSTEM |
| K30 | ENGINE OIL PRESSURE SENSOR (SWITCH) | Op. 1084A INDICATORS/CHECK DEVICES |
| K36 | ENGINE COOLANT TEMPERATURE SENSOR/SENDER UNIT | Op. 1056B MULTI-POINT INJECTION SYSTEM (MPI) |
| K46 | RPM SENSOR | |
| K84 | SPEEDOMETER SENSOR | Op. 2180A MILOMETER CONTROL |
| M001 | BODY COMPUTER | Op. 5505A MULTI-FUNCTION COMPONENTS |
| M010 | ENGINE MANAGEMENT ECU | Op. 1056B MULTI-POINT INJECTION SYSTEM (MPI) |
| N040 | FUEL PUMP AND LEVEL GAUGE | |
| P60 | LEFT DOOR MIRROR | Op. 7005R FRONT DOOR MIRRORS |
Components
Components
Components
| Component code | Description | Reference to the assembly |
|---|---|---|
| B001 | JUNCTION UNIT | Op. 5505A MULTI-FUNCTION COMPONENTS |
| B2 | JUNCTION UNIT UNDER DASHBOARD | Op. 5505A MULTI-FUNCTION COMPONENTS |
| C10 | LEFT FRONT EARTH | |
| C15 | DASHBOARD EARTH, DRIVER''S SIDE | |
| D004 | FRONT/ENGINE COUPLING | |
| E50 | INSTRUMENT PANEL | Op. 5560B ANALOGUE CONTROL PANEL |
| H001 | IGNITION SWITCH | Op. 5520A IGNITION SWITCH |
| I040 | HANDBRAKE SWITCH | Op. 5550D BRAKE AND REVERSING LIGHTS |
| K025 | BRAKE FLUID LEVEL SENSOR (SWITCH) | Op. 3330D BRAKE VACUUM SYSTEM |
| K30 | ENGINE OIL PRESSURE SENSOR (SWITCH) | Op. 1084A INDICATORS/CHECK DEVICES |
| K36 | ENGINE COOLANT TEMPERATURE SENSOR/SENDER UNIT | Op. 1060G DIESEL INJECTION PRESSURE PUMP ELECTRONIC CONTROL |
| K46 | RPM SENSOR | Op. 1060G DIESEL INJECTION PRESSURE PUMP ELECTRONIC CONTROL |
| K84 | SPEEDOMETER SENSOR | Op. 2180A MILOMETER CONTROL |
| K101 | FUEL TEMPERATURE AND WATER IN FUEL FILTER SENSOR | |
| M001 | BODY COMPUTER | Op. 5505A MULTI-FUNCTION COMPONENTS |
| M010 | ENGINE MANAGEMENT ECU | Op. 1060G DIESEL INJECTION PRESSURE PUMP ELECTRONIC CONTROL |
| N040 | FUEL PUMP AND LEVEL GAUGE |
Components
