D75 radio phone coupling

Make

Fiat

Model

Doblò Factory Service Manual

Year

2000–2010

Section

Intermediate couplings › D75 radio phone coupling

Connectors and pin-outsD75 radio phone coupling

D75 RADIO PHONE COUPLING

D075 – Briglia vivavoce

1.4 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V · from 12/03 · MY 2005

Wiring	Colour
See 92 HANDS-FREE BRIDGE	_

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	0,35	BV		See D099 RADIO PHONE PREPARATION COUPLING	1
3	0,35	BN		See D099 RADIO PHONE PREPARATION COUPLING	3
4	0,35	BL		See D099 RADIO PHONE PREPARATION COUPLING	4
5	0,5	BV		See D099 RADIO PHONE PREPARATION COUPLING	5
6	0,5	A		See D099 RADIO PHONE PREPARATION COUPLING	6
7	0,5	V		See D099 RADIO PHONE PREPARATION COUPLING	7
8	0,5	GV		See D099 RADIO PHONE PREPARATION COUPLING	8
9	0,5	BN		See D099 RADIO PHONE PREPARATION COUPLING	9
10	0,5	N		See D099 RADIO PHONE PREPARATION COUPLING	10

1.2 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V, 1.9 DIESEL

Wiring	Colour
See 20 DASHBOARD	bianco

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1		BV		See P20C CAR RADIO ( FACIA )	9
3		BN		See P20C CAR RADIO ( FACIA )	8
4		BL		See P20C CAR RADIO ( FACIA )	7
5	0,5	BV		1
6	0,5	A		2
7	0,5	LV		See B2E JUNCTION UNIT UNDER DASHBOARD ( FACIA )	4
8	0,5	GV		See B2E JUNCTION UNIT UNDER DASHBOARD ( FACIA )	12
9	0,5	BN		See B2E JUNCTION UNIT UNDER DASHBOARD ( FACIA )	8
10	0,5	N		See C15A FACIA EARTH, DRIVER'S SIDE ( FACIA )	6
